Expansion Joint Flange SS316 High Resistance Floating Flanges Connection
Expansion joint flange is a pre-assembled metal bellows unit with integral stainless steel 316 (SS316) flanges featuring a "floating" design. This allows minor angular adjustment during installation to compensate for piping misalignment, while providing high corrosion resistance (especially to chlorides) and sustained high-temperature capability(typically ≤760°C/1400°F) to absorb thermal expansion, vibration, and movement in pressurized piping systems.
Expansion Joint Flange have the following characteristics:
Taking into account the advantages of this product, its service life greatly exceeds that of existing steam hoses. Long term use does not require replacement, greatly reducing usage costs, improving efficiency, and being economical and practical.
Technique Parameter of Metal Expansion Joint
|
Diameter (mm)
|
Pressure grade |
Available Area of Bellows (c㎡)
|
Max Size of External Diameter
|
Length |
|||
|
1.0 |
1.6 |
2.5 |
Flange
|
Tube
|
|||
|
32
|
20/26
|
18/63
|
15/98
|
16
|
225
|
160/250
|
264/280
|
|
40
|
20/24
|
18/89
|
15/98
|
23
|
244
|
164/259
|
269/289
|
|
50
|
20/70
|
18/70
|
15/106
|
37
|
259
|
172/276
|
282/306
|
|
65
|
26/44
|
22/55
|
15/138
|
55
|
270
|
215/294
|
300/322
|
|
80
|
34/33
|
28/41
|
19/68
|
81
|
284
|
240/338
|
344/366
|
|
100
|
40/75
|
35/93
|
25/54
|
121
|
304
|
235/317
|
323/345
|
|
125
|
38/59
|
34/74
|
29/117
|
180
|
334
|
282/314
|
316/342
|
|
150
|
40/62
|
34/78
|
29/92
|
257
|
364
|
282/339
|
338/367
|
|
200
|
59/52
|
53/58
|
46/65
|
479
|
442
|
340/402
|
402/426
|
|
250
|
87/35
|
79/39
|
48/78
|
769
|
507
|
393/459
|
493/399
|
|
300
|
87/37
|
79/41
|
71/47
|
1105
|
562
|
464/525
|
564/565
|
|
350
|
87/44
|
79/48
|
71/45
|
1307
|
622
|
509/564
|
609/604
|
|
400
|
87/43
|
79/47
|
71/47
|
1611
|
562
|
522/566
|
622/628
|
|
450
|
87/37
|
79/41
|
47/75
|
1972
|
700
|
403/498
|
503/523
|
|
500
|
87/68
|
79/75
|
71/45
|
2445
|
760
|
431/523
|
531/554
|
|
600
|
87/85
|
79/94
|
71/82
|
3534
|
835
|
478/548
|
578/588
|
|
700
|
87/77
|
79/85
|
71/103
|
4717
|
1110
|
490
|
590
|
|
800
|
102/102
|
94/112
|
71/95
|
5822
|
1265
|
502
|
602
|
|
900
|
102/97
|
94/107
|
80/123
|
7620
|
1186
|
/
|
698
|
|
1000
|
102/105
|
94/106
|
82/117
|
9043
|
1286
|
/
|
692
|
Expansion Joint Flange details show
Production process of Expansion Joint Flange
Do you know how is a high quality Expansion Joint Flange made?Let's see with JINGNING.
Ptfe Lined Flexible Expansion Joint can be processed into different types according to different needs
Jingning has more than 17 years of design experience in manufacturing flexible expansion joint , rubber expansion joint, metal bellows joint, disassembly joint, pipeline and other industrial pipe fittings. The bellows expansion meets the international standards such as GB, ISO, DIN, ANSI, BS, JIS and the special requirements of customers.
Ptfe Lined Flexible Expansion Joint advantages
1. Ptfe Lined Flexible Expansion Joint is ex factory price
2. 17 years manufacturing experience, 5 years export experience
3. The bellows expansion has strict quality inspection, and the quality far exceeds the industry standard.
4. Various specifications of bellows expansion mold base customization and OEM
5. Free bellows expansion samples
6. Large inventory of bellows expansion
Ptfe Lined Flexible Expansion Joint application
Because of its flexibility, Ptfe Lined Flexible Expansion Joint can compensate the temperature difference deformation or other deformation between equipment and pipeline, prevent vibration, reduce the thrust of pipeline on equipment, and adapt to the uneven settlement of oil tank foundation. The Ptfe Lined Flexible Expansion Joint can be widely used in chemical industry, oil refining, electric power, light industry, atomic energy, metallurgy, machinery, instrument, ship, aerospace and other departments. With the wide application of power pipeline and heat pipeline in industry and civil field, the requirement of bellows expansion is higher and higher.
FAQ
Q1:Can the Ptfe Lined Flexible Expansion Joint be marked with customized logo?
A1:Yes,it can be marked with your logo. We could provide OEM&ODM service.
Q2:What’s the face to face length of Ptfe Lined Flexible Expansion Joint?
A2:The face to face length can be L130, L152,L203... We also could accept customized length according to your requirements.
Q3:Can you provide drawings of Ptfe Lined Flexible Expansion Joint?
A3:Yes,we could provide drawings for you.Please contact us to get the drawing of bellows expansion.
Q4:What certificates of Ptfe Lined Flexible Expansion Joint can you provide?
A4:We could provide CE,ISO certificate.
Q5:Can we get a sample of Ptfe Lined Flexible Expansion Joint?
A5:Yes,we could provide samples for you to test the quality.
